The Japan Mitsubishi PLC control, with touch screen interface system, easy operation, convenient operation, variable speed
Model No.  JHZPS-1   JHZPH-1
Bag Width 80-280mm 80-280mm
Bag Length 130-320mm 130-320mm
Bag Type Stand-up bag, pillow bag Stand-up bag, pillow bag
Packing Speed 10bag/min to
12bag/min to
25 bag/min
Power Supply 220V, 50HZ 220V, 50HZ
Air Consumption 7.0 CFM@80 PSI 7.0 CFM@80 PSI
Pneumatic Parts PIAB Vacuum Generator, Pneumatics component Airtac from Taiwan PIAB Vacuum Generator, Pneumatics component Airtac from Taiwan
. Application:
It's suitable for weighing slice, roll or regular shape products such as sugar, salt, seed, rice, sesame,  milk powder, coffee powder and seasoning powder, etc.
. Main Features:
*High precision digital load cell (HBM load cell is optional)
*Color touch screen (Mouse, SD card and memory card are compatible)
*Multi-language choice (Translation is needed for some specific language)
*Different authority management
III. Special Features:
*Weighing mix different products at one discharge
*Parameters can be freely adjusted during running condition
*New generation design, each actuator、boards can exchange with each other.
*Self-diagnose function on the electronic boards
. Specification:
Model VM4N25
Range of single bag weight 10-2000g
AV SNGL bag ERR / Weighing Accuracy 0.2-2g
Max weighing speed 10-60 bags/min
hopper Capacity 3L
Control system MCU
Preset Programs 10
Max. Mix-Products 4
Operation Panel 7 inch touch screen
Voltage/Power/Frequency/Rating Current AC220V ±10% 50Hz(60Hz)
Packing Dimension (mm) 1010(L)*960(W)*1207(H)
Packing Weight 250KG
Model JHZPE-1
Packing type  flat bag, three side seal, four side seal, zipper bag.
packaging bag size W:100-200mm   L:150-320mm
weight 10-1000g
Speed 16 to 40bag/min
Packing accuracy ≤±1%
power 3.85KW,AC380V,50HZ
size 4600*22000*3700mm
