JHS-P Stainless Steel Tea Pet Food Powder Mixer

\
JINHE New Factory Video: https://www.youtube.com/watch?v=rGOYaFf6Ot8

\

Introduction:

JHS-P Stainless Steel Pet food tea coffee granule Mixer is using to combine small batches products and with spraying little amount liquid.To ensure its consistency and quality.This task requires the mixer with big capacity, stable working and easy to use.But have low requirement of the mixing uniformity.
Unique Mixing Principle:
Fixed helical blades shearing and shunting on powders.Solve the low convection of traditional double cone mixer and get better uniformity.JHS Double Cone Mixer own proprietary intellectual property rights and with advanced mixing technology.

\
​Youtube Address:    www.youtube.com/user/asiamixer

\\\
\
\
\\
\
\
1. Mixer Specification


Model Max
Capacity
(L)
Max Barrel
Weight
Capacity
(Kg)
Barrel
Wall
Thickness
(mm)
Barrel
 Speed
(r/min)
Motor
Power
(KW)
Size(mm) Weight
(kg)
JHS-P300

300 150 3 24 2.2 2200*1100*1650 450
JHS-P500

500 250 4 24 3 2700*1280*1950 600
JHS-P
1000

1000 500 4 10 7.5 2850*1420*2450 1400
JHS-P
2000

2000 1000 5 10 11 3050*1550*2600 3800
JHS-P
3000

3000 1500 6 8 18.5 3000*1800*3000 5500
JHS-P
5000

5000 2500 6 6 30 4100*2100*3300 7800
JHS-P
10000

10000 5000 8 5 55 4900*3200*4500 11000
JHS-P
20000

20000 10000 8 4 75 5300*3400*5000 13000
JHS-P
28000

28000 14000 8 4 110 5961*3390*5833 15000
Application:
1. Dry powders or half dry powders,mainly used in Powder Metallurgy,Chemical,Rare Earth,Phamaceutical,Food Industry.
2. Special for large batches,heavy tonnage products mixing.
3. Special for compounding small batches products into large batches to ensure its consistency and quality.


Finished Products:

\\
\
\
\\\
\

Operating rules

1、Machine inspecting. Install the machine, adjust the barrel, be subject to rotating flexible. Barrel is a rotating part, operator should not be close to the working machine for fear be injured.

2、Loading materials. Filling powder materials through loading port, the optimum loading rate is 45%-50%. After finish filling materials, close covering cap of loading port and adjust mixing time.

3、Settle mixing time. Mixing time can be controlled by time, it should be set up well before mixer machine working. When the machine works to the preset time, it will stop automatically( during this, press stop button ,the machine can also stop working.

4、JHS-P Paint powder mixing machine Starting up.

    A、Press button “preparation” + “operate”  or “shake”, the machine starts to work. This double keying operation method is for operator’s safety, prevent personal injury caused by one keying misuse.

B、 During mixer machine working, turn on the spray pump, it will spray fluid into the rotating barrel. When the fluid spray capacity meet material needs, please manually turn off power of the spray pump.

  Note: This operation is independent; it is not associated with mixer machine’s working condition.

    C、When the mixer machine stop working, switch on the spray pump, its working condition can be checked in real time.

5、Discharge materials. Press button “stop” to end mixing, let the discharge port rotate to the right below position by pressing “shaking” button, put a loading container at lower end of discharge port, open the valve of discharge port until all the materials discharge completely.

JHS-P stainless steel tea coffee powder mixer--Fluid Injection System Operating Instructions

1. Notice

      A, Before use the metering pump, please add gear lubricant to oil pointer

      B, Before switch on the metering pump, make sure that the pipeline is unobstructed (valve open)

      C, When the metering pump stop working, make sure that shut off the metering pump firstly, then close the fluid outlet pipe valve.

      D, Outlet line pressure must be greater than the inlet line pressure.

      E, Avoid metering pump pumping fluid contains solid particles.

2.Inspect working position of the fluid injection system before equipment working

      A, Disconnect spray pump outlet pipe

      B, Make sure that there is sufficient amount of liquid in the fluid tank.

      C, Open the manual power switch of the spray pump and it begin to work independently. Observe if there is liquid outflow, if yes, it means the machine is normal. Otherwise, please detect the cause of the fault.

      D, Inspect spray nozzle in the barrel clogged or not, if yes, please clean up.

3.Preparation work on the fluid spray system before mixer machine starting up

      A, Adjust flow rate of fluid through manual operation rotating rod behind the liquid pump (adjust the rate between 50%-100% of the rated flow).

      B, Make sure that there is sufficient amount of liquid in the fluid tank.
\
