Working Principle:

The disc is disk-shaped, With equidistance width up and down at the edge. Slant height at axial makes pushing action and produces non-uniform flow to material when dispersing(viscosity shearing force caused by velocity contrast). Disc runs at high and stable speed, produces shearing and crashing force to material. At normal operation, rotation of disc forms rolling circulation of material, and disc can be partial seen which indicates that max mechanical energy has input material. Material can get full circulating and stirring with the continuous rotation of disc. Granulates at material surface will drop to the circulation bottom, forming a 2.5-5 cm turbulence flow at the edge of disc. Material at this district will bear strong shearing and crashing force, highly dispersing.

Application:

This stainless steel dispersing machine for paint, emulsion, adhesive, petroleum, chemical, rubber, pesticide, dye, medicine and food industry. Used to achieve curing, hydrogenation, alkylation, polymerization, condensation process. Food procession, cosmetics production, chemical industry, dyeing and printing facilities, essence and fragrant substance production, fine chemical industry, emulsification of diesel oil pitch.



Liquid Tank:


Application Area:

1. Paints Producing
2. Coatings Manufacturing
3. Pigments Producing
4.Inks Manufacturing
5.Dyestuff Producing
6. Paper Making Process
7. Glue Mixing
8. Pesticide Manufacturing
9. Low Viscosity Chemicals Dissolving
10. Liquid Chemicals Mixing

Parameter Technology:

Model
Power(kw)
Speed(rpm)
Hydraulic Power(kw)
Capcaity (L)
Disc Dia (mm)
Lifting (mm)
GW(kg)
JHLY-1.5
1.5
0-1440
0.55
20-100
100
500
350
JHLY-2.2
2.2
0-1440
0.75
50-150
150
600
400
JHLY-4
4
0-1440
0.75
50-200
200
700
450
JHLY-5.5
5.5
0-1440
0.75
80-250
200
800
600
JHLY-7.5
7.5
0-1440
1.1
100-300
250
800
700
JHLY-11
11
0-1440
1.1
100-400
250
900
750
JHLY-15
15
0-1440
1.1
100-500
300
900
800
JHLY-18.5
18.5
0-1440
1.1
100-800
300
1100
1000
JHLY-22
22
0-1440
1.1
150-1000
300
1100
1100
JHLY-30
30
0-1440
1.1
200-1200
350
1100
1200
JHLY-37
37
0-1440
1.5
300-1200
400
1200
1300
JHLY-45
45
0-1440
1.5
500-2000
150
1200
1400
JHLY-55
55
0-1440
1.5
1000-2000
500
1300
1500
JHLY-75
75
0-1440
2.2
2000-4000
550
1800
3000
JHLY-90
90
0-1440
2.2
4000-6000
580
2300
3500
